Name: GT-550
Category: Five-axis Machining Center
Product details
The machine tool is a sliding saddle five-axis linkage machining center. The basic frame of the machine tool has the advantages of strong rigidity, symmetrical structure and strong stability. At the same time, it introduces the international advanced dynamic rigid design concept and optimizes the design of moving parts. The machine tool has strong rigidity and fast response characteristics, which can meet the requirements of high-precision aerospace parts processing and various high-precision mold processing fields. |
| PROJECT | DESCRIPITION | UNIT | GT-550 | |
| TRAVEL | Type of XYZ Axis Guide | High Rigid Roller Rail | ||
| X-axis/Y-axis/Z-axis | mm | 800/520/465 | ||
| B-Axis Travel (Swing Axis) | ° | +30~-100 | ||
| C-Axis Travel (Rotating Axis) | ° | 0~-360 | ||
| Spindle nose end to working table | mm | 220-680（approximate value） | ||
| TABLE | Workbench diameter | mm | 550（optional650） | |
| Workbench load-bearing | kg | 300（level）/250（0°~-90°tilt） | ||
| SPINDLE | Spindle speed/ RPM | rpm | CVT15000rpm | |
| Spindle bore taper /TYPE | HSK-A63 | |||
| FEED RATE | C00 Fast Feed (X/Y/Z) | mm/min | 30000/30000/20000 | |
| G01 Cutting Feed | mm/min | 1-8000 | ||
| PRECISION | Location accuracy/repetition accuracy | X/Y/Z Axis | mm | 0.01/0.008 |
| Axis B (Swing Axis) | " | 50/8 | ||
| Axis C（Rotating Axis） | " | 15/6 | ||
| OTHER | Machine weight | kg | 10000（About） | |
