Home > Products center > High Speed Milling
-
Name: GT-2215
Category: High Speed Milling
Product details
| PROJECT | DESCRIPITION | UNIT | MT-2215 |
| TRAVEL | X-axis/Y-axis/Z-axis | mm | 2200/1500/800 |
Spindle nose end to working table(approximate value) | mm | 180-980 | |
| Distance between two columns(approximate value) | mm | 1580 | |
| TABLE | Workbench (long x wide) | mm | 2200×1480 |
| maximum payload | kg | 6000 | |
| SPINDLE | Spindle speed/RPM | rpm | 15000/20000 |
Spindle bore taper/TYPE | HSK-A63 | ||
| FEED RATE | C00 Fast Feed (X/Y/Z) | mm/min | 15000/15000/10000 |
| G01 Cutting Feed | mm/min | 1-7500 | |
| PRECISION | Location accuracy/repetition accuracy | mm | 0.01/0.008 |
| OTHER | Machine weight | kg(About) | 18000 |
